General type |
B/W Multifunctional for A4/A3 format |
Technology |
KYOCERA Laser Monochrome, HyPAS™ solution platform |
Engine speed |
Up to 40/21 pages per minute A4/A3 |
Resolution |
1200 x 1200 dpi (print, at reduced speed) 600 x 600 dpi (scan/copy) |
Warm-up time |
Approx. 18 seconds or less from power on |
Time to first print |
Approx. 4.2 seconds or less |
Time to first copy |
Approx. 4.6 seconds or less (DP) Approx. 3.6 seconds or less (Platen Cover) |
Dimensions (W x D x H) |
Main Unit: 594 x 696 x 683 mm |
Weight |
Main unit incl. toner: Approx. 59.25 kg |
Power consumption |
Printing: 600 W, Stand-by: 100 W, Energy saving priority: 1.0 W or less |
Power source |
AC 220 V ~ 240 V, 50/60 Hz |
Noise (ISO 7779 / ISO 9296) |
Noise (sound pressure level ISO 7779/ISO 9296) Printing/copying: 67 dB(A) LpA, Stand-by: 43 dB(A) LpA |
Safety standards |
GS, TÜV, CE – This unit is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. |
General memory |
Standard 2048 MB, 8 GB SSD + standard 320 GB HDD |
Input capacity |
100-sheet multi-purpose tray, 45–256 g/m² (A3, A4, A5, A6, B5, Ledger, Letter, Legal, Folio, Custom (98 x 148 to 297 x 432 mm); 2 x 500-sheet standard universal paper cassette, 60–163 g/m², (A3, A4, A5, B5, Ledger, Letter, Legal, Folio) |
Max. input capacity with options |
4,100 sheets A4 |
Duplex unit |
Duplex as standard supports A5R–A3, 60–160 g/m² |
Output capacity |
Standard 300 sheets, 250 sheets face-down (Main Tray) plus 50 sheets (standard Job Separator Tray), Max 3,200 sheets with options |
Further information |
All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by Kyocera under normal environmental conditions. |
Processor |
Freescale QorIQ T1024**** (Dual Core) 1.0 GHz |
Controller language |
PRESCRIBE IIe |
Emulations |
PCL6 (5e/XL), KPDL3 (PostScript 3 compatible), PDF Direct Print, XPS Direct Print and Open XPS, PPML |
Fonts |
93 outline fonts (PCL), 136 fonts (KPDL 3), 8 fonts( Windows Vista), 1 Bitmap font; 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417) |
Features |
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec,SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality |
Standard Interface (Print) |
USB 2.0 (Hi-Speed), 4 x USB Host Interface, Gigabit Ethernet (10BaseT/100BaseTX/1000BaseT, IPv6, IPv4, IPSec, 802.3az support), optional Wi-Fi (IEEE 802.11b/g/n), 2 eKUIO slots, for optional internal print server or for optional fax system, Slot for optional SD Card, NFC tag |
Applicable OS (Print) |
All current Windows operating systems MAC OS X Version 10.5 or higher Unix, Linux as well as other operating systems on request |
Max. original size |
A3/Ledger |
Digital features |
Scan-once-copy-many, electronic sort, 2in1, 4in1, image repeat, page numbering, cover mode. booklet copy, interrupt copy, form overlay, margin shift, auto cassette change, Skip blank page, ID copy in Program mode |
Exposure modes |
Auto, manual: 17 steps |
Preset magnification ratios |
5 Reductions/ 5 Enlargements |
Zoom range |
25 – 400 in 1% steps |
Continuous copy |
1 – 999 |
Image adjustments |
Text, Text + Photo, Photo, Map, Printed Document |
File type |
TIFF, PDF, PDF/A, JPEG, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u |
Scan features |
Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip |
Original recognition |
Text, Photo, Text + Photo, light text, optimised for OCR |
Max. scan size |
A3/Ledger, Banner up to 1,900 mm |
Scan functionalities |
Scan-to-email, Scan-to-FTP, Scan-to-SMB, Scan-to-USB Host, Scan-to-box, Network TWAIN, WIA, WSD scan |
Scan resolution |
600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 400 dpi, 200 x 200 dpi, 200 x 100 dpi; 256 greyscales per colour |
Scan speed |
(A4, 300 dpi, Dual Scan with DP-7110/DP-7100) 160 originals per minute in b/w, 160 originals per minute in colour |
Compatibility |
ITU-T Super G3 |
Modem speed |
33.6 kbps |
Scanning speed |
2.0 seconds or less |
Transmission speed |
Max. 3 seconds (JBIG) |
Scanning density |
Normal: 8 dot/mm x 3.85 line/mm (200 x 100 dpi) Fine: 8 dot/mm x 7.7 line/mm (200 x 200 dpi) Superfine: 8 dot/mm x 15.4 line/mm (200 x 400 dpi) Ultrafine: 16 dot/mm x 15.4 line/mm (400 x 400 dpi) Halftone: 256 grey scales |
Max. original size |
A3/Ledger, Banner max. 1,600 mm |
Compression method |
MH, MMR, MR, JBIG |
Fax features |
Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast, optional internet fax, dual fax with second fax system 12 |
