Produktivitas tinggi, ukurannya kecil
Memperkenalkan perangkat multifungsi A4 mono ringkas dengan kemampuan pemindaian cepat dan konektivitas seluler canggih. Dapat diandalkan dan serbaguna, seri Canon iR 1643 menawarkan berbagai fungsi yang disesuaikan dengan tuntutan kelompok kerja yang sibuk.
A4/F4 Monokrom
Kecepatan cetak hingga 43 halaman per menit
Copy, Print, Scan, Send
DADF
Duplex
Layar sentuh warna 5 inch
Perpustakaan Aplikasi
Perpustakaan Aplikasi dikemas dengan inovasi untuk membantu Anda bekerja lebih cerdas dan lebih efisien dari sebelumnya. Anda dapat mencetak formulir yang sering digunakan dari printer, atau mempersonalisasikan printer dengan logo perusahaan Anda hanya dengan satu ketukan tombol.
Peningkatan Produktivitas
Tingkatkan efisiensi alur kerja Anda dengan output cepat, kapasitas input kertas yang besar, dan dukungan media yang kaya. Pengumpan dokumen single-pass dengan pemindaian dua sisi otomatis memastikan pemrosesan digitalisasi dokumen pada posisi optimal.
Kontrol Intuitif Canon iR 1643i memiliki layar sentuh warna yang sederhana dan intuitif, memungkinkan kustomisasi tugas sehari-hari yang mudah melalui ikon pada layar yang dapat dipilih.
Keamanan Tinggi
Kontrol akses dan jaga kerahasiaan file Anda dengan serangkaian opsi keamanan dan enkripsi tingkat lanjut. Canon iR1643 juga menyertakan teknologi terbaru untuk memverifikasi bahwa proses boot perangkat, firmware, dan aplikasi dijalankan tanpa perubahan atau gangguan.
Konektivitas Seluler
Cetak, pindai, atau kirim dokumen dari perangkat portabel apa pun melalui berbagai koneksi seluler. Dengan solusi bisnis seluler terbaru Canon, Anda dapat mencetak dokumen, foto, dan halaman web hanya dengan satu aplikasi.
NETWORK Standard:
1000Base-T/100Base-TX/10-Base-T, Wireless LAN (IEEE 802.11 b/g/n), Wi-Fi Direct ConnectionOTHERS Standard:
USB 2.0 (Host) x2, USB 2.0 (Device) x1
Memory Media
Standard: USB Memory
Network Security
Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP
Upper Cassette 1:
Standard size: A4, B5, A5, A5R, A6
Custom size: Min. 105.0 x 148.0 mm up to 216.0 x 355.6 mmMulti-purpose tray:
Standard size: A4, B5, A5, A5R, A6, Index Card, Envelopes [No. 10(COM 10), Monarch, ISO-C5, DL]
Custom Size: Min. 76.2 x 127.0 mm up to 216.0 x 355.6 mm
Supported Media Weights
Upper Cassette 1: 60 to 120 gsm
Multi-purpose tray: 60 to 199 gsm
Duplex: 60 to 120 gsm
Warm-up Time
(Time from device power-on until copy ready, not print reservation)
From Power On: 14 Seconds or Less*1
From Sleep Mode: 4 Seconds or Less
Dimensions (W x D x H)
iR1643i: 480 x 595 x 452 mm (with the multi purpose tray extended)
Installation Space (W x D)
iR1643i: 694 x 1,105 mm (with Cassette open + 100 mm gap around the main body)
Weight
Standard: Approx. 19 kg without toner
Print
Print Speed (BW)
43 ppm (A4)
Print Resolution (dpi)
600 × 600
Page Description Languages
iR1643i: UFR II, PCL6, PCL5, Optional: Adobe®PostScript®3™
Direct Print
Direct printing available from USB memory, LPR
Supported file types: TIFF, JPEG, PDF and XPS (only LPR)
Fonts
PCL fonts: 93 Roman
PS fonts: 136 Roman
Operating System
UFRII/PCL/PS: Windows®7/8.1/10/Server2008/Server2008 R2/Server2012/Server2012 R2/Server2016, Mac OS X (10.9 or later)
Copy
Copy Speed (ppm)
43 ppm (A4)
First-Copy-Out Time (A4)
Platen: Approx. 6.3 seconds or less
ADF: Approx. 6.4 seconds or less
Copy resolution (dpi)
Reading / Printing: 600 x 600
Printing: 600 x 600
Multiple Copies
Up to 999 copies
Copy Density
Automatic or Manual (9 Levels)
Magnification
25% – 400% (1% Increments)
Preset Reductions
25%, 50%, 70%, 81%, 86%
Preset Enlargements
115%, 122%, 141%, 200%, 400%
Scan
Document Feeder Type
1PDS
Paper Capacity
A4: 50 sheets (80 gsm)
Acceptable Originals and Weights
Platen: Sheet, Book, 3-Dimensional Objects (Height: up to 20mm)
Document Feeder sheet media weight :
1-sided/2-sided continuous scanning: 50 to 105 gsm
Supported Media Sizes
Sheet media size: A4R, B5R, A5R, A6R
Custom size: 105×128 mm to 215.9×355.6 mm
Copy: 600 x 600
Send (Push, Pull)/Fax: up to 600 x 600
Pull Scan Specifications
ScanGear MF For both TWAIN and WIA ScanGear MF For both TWAIN and WIA
Windows® 7/8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016, Mac OS X (10.9 or later)
Scan Method
Send functionality available on both models
Scan to USB Memory Key
TWAIN/WIA Pull scanning available on both models
Send
Destination
E-mail/Internet FAX (SMTP), SMB, FTP
Address Book
LDAP (50)/Local (300)/Speed dial (281)
Send Resolution (dpi)
Push: 196 x 204 (I-FAX)
300 x 300 (email/SMB/FTP)
Pull: Max. 9,600 x 9,600
